Aug 11, 2022
- Weight 23,000
- 2500mm cutting width
- 400mm maximum depth
- 0-5km/h working speeds
- 0-20km/h travel speed
- 460hp Weichai diesel
- Joystick driving and steering controls
Aug 11, 2022
- Engine Model WP12.400N
- Rated power/speed (kW/rpm) 294
- Working speed (km/h) 0-3
- Traveling speed (km/h) 0-23
- Theoretical gradeability (%) 20
- Ground clearance (mm ) 450
- Working weight (kg) 15600
- Maximum Milling width (mm) 2100
- Maximum milling depth (mm) 0-400
- Amount of tools pcs 168
- Overall dimensions (mm) 8740×2765×3450
- Fuel tank (L) 450
- Hydraulic oil tank (L) 450
Aug 11, 2022
- Weight ≤72,000
- Engine Model WP13G530E310
- Rated power/speed (kW/rpm) 390
- Working speed (km/h) 0-3.2/4
- Traveling speed (km/h) 0-22.8/29
- Theoretical gradeability (% ) ≥20
- Ground clearance (mm) 350
- Working weight (kg) 26500/22500
- Maximum Milling width (mm) 2100/2300
- Maximum milling depth (mm) 400
- Amount of tools pcs 162
- Rotor diameter (mm) 1380
- Fuel tank (L) 650
- Hydraulic oil tank (L) 380
- Water tank (L) 1000
